Moore-Spence turning point solver strategy based on "Salinger" bordering. This is the classic 4-solve bordering method. More...

#include <LOCA_TurningPoint_MooreSpence_SalingerBordering.H>

Inheritance diagram for LOCA::TurningPoint::MooreSpence::SalingerBordering:

[legend]

Collaboration diagram for LOCA::TurningPoint::MooreSpence::SalingerBordering:

[legend]

Public Member Functions
	SalingerBordering (const Teuchos::RCP< LOCA::GlobalData > &global_data, const Teuchos::RCP< LOCA::Parameter::SublistParser > &topParams, const Teuchos::RCP< Teuchos::ParameterList > &solverParams)
	Constructor.

virtual	~SalingerBordering ()
	Destructor.

virtual void	setBlocks (const Teuchos::RCP< LOCA::TurningPoint::MooreSpence::AbstractGroup > &group, const Teuchos::RCP< LOCA::TurningPoint::MooreSpence::ExtendedGroup > &tpGroup, const Teuchos::RCP< const NOX::Abstract::Vector > &nullVector, const Teuchos::RCP< const NOX::Abstract::Vector > &JnVector, const Teuchos::RCP< const NOX::Abstract::MultiVector > &dfdp, const Teuchos::RCP< const NOX::Abstract::MultiVector > &dJndp)
	Set blocks in extended linear system.

virtual NOX::Abstract::Group::ReturnType	solve (Teuchos::ParameterList &params, const LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &input, LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &result) const
	Solves the extended system as defined above.

virtual NOX::Abstract::Group::ReturnType	solveTranspose (Teuchos::ParameterList &params, const LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &input, LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &result) const
	Solves the transpose of the extended system as defined above.

Public Member Functions inherited from LOCA::TurningPoint::MooreSpence::SolverStrategy
	SolverStrategy ()
	Constructor.

virtual	~SolverStrategy ()
	Destructor.

Protected Member Functions
NOX::Abstract::Group::ReturnType	solveContiguous (Teuchos::ParameterList &params, const NOX::Abstract::MultiVector &input_x, const NOX::Abstract::MultiVector &input_null, const NOX::Abstract::MultiVector::DenseMatrix &input_param, NOX::Abstract::MultiVector &result_x, NOX::Abstract::MultiVector &result_null, NOX::Abstract::MultiVector::DenseMatrix &result_param) const
	Solves equations with contiguous arguments.

NOX::Abstract::Group::ReturnType	solveTransposeContiguous (Teuchos::ParameterList &params, const NOX::Abstract::MultiVector &input_x, const NOX::Abstract::MultiVector &input_null, const NOX::Abstract::MultiVector::DenseMatrix &input_param, NOX::Abstract::MultiVector &result_x, NOX::Abstract::MultiVector &result_null, NOX::Abstract::MultiVector::DenseMatrix &result_param) const
	Solves equations with contiguous arguments.

Protected Attributes
Teuchos::RCP< LOCA::GlobalData >	globalData
	Global data object.

Teuchos::RCP< Teuchos::ParameterList >	solverParams
	Solver parameters.

Teuchos::RCP< LOCA::TurningPoint::MooreSpence::AbstractGroup >	group
	Underlying group.

Teuchos::RCP< LOCA::TurningPoint::MooreSpence::ExtendedGroup >	tpGroup
	Turning point group.

Teuchos::RCP< const NOX::Abstract::Vector >	nullVector
	Null vector.

Teuchos::RCP< const NOX::Abstract::Vector >	JnVector
	Jacobian times null vector.

Teuchos::RCP< const NOX::Abstract::MultiVector >	dfdp
	df/dp

Teuchos::RCP< const NOX::Abstract::MultiVector >	dJndp
	d(Jn)/dp

Detailed Description

Moore-Spence turning point solver strategy based on "Salinger" bordering. This is the classic 4-solve bordering method.

This class solves the Moore-Spence turning point Newton equations:

$\begin{bmatrix} J & 0 & f_p \\ (Jv)_x & J & (Jv)_p \\ 0 & \phi^T & 0 \end{bmatrix} \begin{bmatrix} X \\ Y \\ z \end{bmatrix} = \begin{bmatrix} F \\ G \\ h \end{bmatrix}$

via the following block elimination scheme:

$\begin{split} J [A \; b] &= [F \; f_p] \\ J [C \; d] &= (Jv)_x[A \; b] - [G \; (Jv)_p] \\ z &= (h + \phi^T C) / \phi^T d \\ X &= A - b z \\ Y &= -C + d z \end{split}$

Constructor & Destructor Documentation

◆ SalingerBordering()

LOCA::TurningPoint::MooreSpence::SalingerBordering::SalingerBordering	(	const Teuchos::RCP< LOCA::GlobalData > &	global_data,
		const Teuchos::RCP< LOCA::Parameter::SublistParser > &	topParams,
		const Teuchos::RCP< Teuchos::ParameterList > &	solverParams
	)

Constructor.

Parameters

global_data	[in] Global data object
topParams	[in] Parsed top-level parameter list
solverParams	[in] Bordered solver parameters. Currently none are referenced.

Member Function Documentation

◆ setBlocks()

void LOCA::TurningPoint::MooreSpence::SalingerBordering::setBlocks	(	const Teuchos::RCP< LOCA::TurningPoint::MooreSpence::AbstractGroup > &	group,
		const Teuchos::RCP< LOCA::TurningPoint::MooreSpence::ExtendedGroup > &	tpGroup,
		const Teuchos::RCP< const NOX::Abstract::Vector > &	nullVector,
		const Teuchos::RCP< const NOX::Abstract::Vector > &	JnVector,
		const Teuchos::RCP< const NOX::Abstract::MultiVector > &	dfdp,
		const Teuchos::RCP< const NOX::Abstract::MultiVector > &	dJndp
	)

virtual

Set blocks in extended linear system.

Parameters

group	[in] Underlying group representing J
tpGroup	[in] Turning point group representing the turning point equations.
nullVector	[in] Vector representing v
JnVector	[in] Vector representing Jv
dfdp	[in] Vector representing df/dp
dJndp	[in] Vector representing d(Jv)/dp

Implements LOCA::TurningPoint::MooreSpence::SolverStrategy.

◆ solve()

NOX::Abstract::Group::ReturnType LOCA::TurningPoint::MooreSpence::SalingerBordering::solve	(	Teuchos::ParameterList &	params,
		const LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &	input,
		LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &	result
	)		const

virtual

Solves the extended system as defined above.

The params argument is the linear solver parameters.

Implements LOCA::TurningPoint::MooreSpence::SolverStrategy.

References LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getNullMultiVec(), LOCA::Extended::MultiVector::getScalars(), LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getXMultiVec(), and LOCA::Extended::MultiVector::numVectors().

◆ solveTranspose()

NOX::Abstract::Group::ReturnType LOCA::TurningPoint::MooreSpence::SalingerBordering::solveTranspose	(	Teuchos::ParameterList &	params,
		const LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &	input,
		LOCA::TurningPoint::MooreSpence::ExtendedMultiVector &	result
	)		const

virtual

Solves the transpose of the extended system as defined above.

The params argument is the linear solver parameters.

Reimplemented from LOCA::TurningPoint::MooreSpence::SolverStrategy.

References LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getNullMultiVec(), LOCA::Extended::MultiVector::getScalars(), LOCA::TurningPoint::MooreSpence::ExtendedMultiVector::getXMultiVec(), and LOCA::Extended::MultiVector::numVectors().

The documentation for this class was generated from the following files:

LOCA_TurningPoint_MooreSpence_SalingerBordering.H
LOCA_TurningPoint_MooreSpence_SalingerBordering.C
