Abstract strategy for solving the Moore-Spence Hopf equations. More...
#include <LOCA_Hopf_MooreSpence_SolverStrategy.H>
Inheritance diagram for LOCA::Hopf::MooreSpence::SolverStrategy:
Public Member Functions | |
| SolverStrategy () | |
| Constructor. | |
| virtual | ~SolverStrategy () |
| Destructor. | |
| virtual void | setBlocks (const Teuchos::RCP< LOCA::Hopf::MooreSpence::AbstractGroup > &group, const Teuchos::RCP< LOCA::Hopf::MooreSpence::ExtendedGroup > &hopfGroup, const Teuchos::RCP< const NOX::Abstract::Vector > &yVector, const Teuchos::RCP< const NOX::Abstract::Vector > &zVector, const Teuchos::RCP< const NOX::Abstract::Vector > &CeRealVector, const Teuchos::RCP< const NOX::Abstract::Vector > &CeImagVector, const Teuchos::RCP< const NOX::Abstract::Vector > &dfdp, const Teuchos::RCP< const NOX::Abstract::Vector > &dCedpReal, const Teuchos::RCP< const NOX::Abstract::Vector > &dCedpImag, const Teuchos::RCP< const NOX::Abstract::Vector > &ByVector, const Teuchos::RCP< const NOX::Abstract::Vector > &mBzVector, double w)=0 |
| Set blocks in extended linear system. | |
| virtual NOX::Abstract::Group::ReturnType | solve (Teuchos::ParameterList ¶ms, const LOCA::Hopf::MooreSpence::ExtendedMultiVector &input, LOCA::Hopf::MooreSpence::ExtendedMultiVector &result) const =0 |
| Solves the extended system as defined above. | |
Detailed Description
Abstract strategy for solving the Moore-Spence Hopf equations.
This class provides an abstract interface for solver strategies to solve the Moore-Spence Hopf Newton system:
![\[
\begin{bmatrix}
J & 0 & 0 & 0 & f_p \\
(Jy-wBz)_x & J & -wB & -Bz & (Jy-wBz)_p \\
(Jz+wBy)_x & wB & J & By & (Jz+wBy)_p \\
0 & \phi^T & 0 & 0 & 0 \\
0 & 0 & \phi^T & 0 & 0
\end{bmatrix}
\begin{bmatrix}
X \\
Y \\
Z \\
\Omega^T \\
\Lambda^T
\end{bmatrix} =
\begin{bmatrix}
F \\
G \\
H \\
U^T \\
V^T
\end{bmatrix}.
\]](form_537_dark.png)
After instantiating a solver (via LOCA::Hopf::MooreSpence::SolverFactory), the linear system is set up by setBlocks() and can then be solved by solve().
Member Function Documentation
◆ setBlocks()
|
pure virtual |
Set blocks in extended linear system.
- Parameters
-
group [in] Underlying group representing J hopfGroup [in] Hopf group representing the Hopf equations. yVector [in] Vector representing y zVector [in] Vector representing z CeRealVector [in] Vector representing Jy-wBz CeImagVector [in] Vector representing Jz+wBy dfdp [in] Vector representing df/dp dCedpReal [in] Vector representing d(Jy-wBz)/dp dCedpImag [in] Vector representing d(Jz+wBy)/dp ByVector [in] Vector representing By mBzVector [in] Vector representing -Bz w [in] Bifurcation frequency w
Implemented in LOCA::Hopf::MooreSpence::SalingerBordering.
◆ solve()
|
pure virtual |
Solves the extended system as defined above.
The params argument is the linear solver parameters.
Implemented in LOCA::Hopf::MooreSpence::SalingerBordering.
The documentation for this class was generated from the following file:
- LOCA_Hopf_MooreSpence_SolverStrategy.H
